Fischer ME01 – Vibration resistant Pressure Transmitter – liquids, gases

Working Principle:

Fischer ME01 pressure sensor consists of ceramic measuring cell. The high durability of the ceramic material allows the pressure transmitter to be employed with aggressive media. A Wheatstone’s bridge is attached to diaphragm’s opposite side to the measured media.

As the measured pressure is applied, it causes the diaphragm to be strained. The resistance values of the Wheatstone bridge change according to applied pressure. These values are displayed and transmitted as electrical analog output signal.

Key Features:

• Direct measurement, without transfer fluid
• High vibration resistance
• High accuracy
• High overpressure safety
• Minimum hysteresis

Key Specifications:

• Measuring range:
  • 0 ~ 1.6 bar to 0 ~ 60 bar (overpressure safety: 3.2 bar ~ 120 bar)
  • -1.0 ~ 0.0 bar to -1.0 ~ 15 bar (overpressure safety: 2 bar ~ 32 bar)
• Linearity: < 1% full scale
• Hysteresis: < 0.5% full scale
• Permissible ambient temperature: 0° C ~ 60° C
• Permissible media temperature: 0° C ~ 100° C
• Nominal power supply: 24V DC
• Output Signal: 0~20mA / 4~20mA / 0~10V, 3-wire
• Ingress protection: IP65 acc. to DIN EN 60529
• Temperature drift, zero: 0.4% full scale / 10K
• Temperature drift, range: 0.05% full scale / 10K
• Electrical connection: connection plug M16 x 1.5 acc. to DIN EN 175301-803
• Material, medium contact: AISI 316L (1.4404), gasket: Viton
• Material, body: AISI 304 (1.4305)

Industrial areas:

• Chemical industries
• Machine and plant engineering
• Process engineering
• Manufacturing industries
• Glass and silicon industries
